Starting and operating

tial and rear differential. This sound
occurs because of the structure of the
center differential. It does not indicate a
problem.

7-19

& Auto mode

& To change mode of driver’s
control center differential

1)
2)
3)
4)
A)
B)

LSD torque
Traction torque
Initial LSD torque (maximum)
Initial LSD torque (minimum)
Initial LSD torque (adjustable)
Mechanical LSD torque

The driver’s control center differential has
an auto mode and a manual mode. In the
auto mode, the system automatically
adjusts the initial LSD torque. In the
manual mode, you can change to the
desired mode manually by using the
center differential control switch.

NOTE

Press the “AUTO-MANU” switch on the
center console to switch from auto mode
to manual mode or vice versa. When you
select the auto mode, the “AUTO” indicator light illuminates. When you select the
manual mode, the “AUTO” indicator light
turns off.

In the auto mode, the system estimates
the driving and road conditions using
signals from the wheel speed sensor,
throttle position sensor, steering angle
sensor and brake switch, etc. According
to the result, it electronically and automatically controls the degree of limitation
of the differential action (LSD torque) to
optimize the differential action of the
center differential. When the ignition
switch is turned ON, the “AUTO” indicator
light on the combination meter illuminates.

If you rapidly depress and release the
accelerator pedal while driving at low
speed, you may hear a knocking sound
from the vicinity of the center differen– CONTINUED –
