5-42

Audio

counterclockwise, the displayed category
changes in the opposite sequence.

NOTE
When an iPod® is connected, you
cannot select a folder.

& When “CHECK DEVICE” is
displayed

To select the category, press the “TUNE/
TRACK/CH” dial. To close the iPod®
menu, press the “LIST” button for more
than 1.5 seconds. To return to the previous screen, briefly press the “LIST”
button.

& Display selection
Refer to “Display selection” F5-30.
! Page scroll
Refer to “Page (track/folder title) scroll”
F5-31.

& Folder selection (only when
connecting USB storage device)
Refer to “Folder selection” F5-31.

This message is displayed under the
following conditions.
. When there is a short in the USB bus
. When a non-corresponding device (for
example a USB mouse) is connected
. When a non-corresponding iPod® is
connected
. When a connected iPod® is frozen
. When a transmission malfunction occurs
. When an iPod® confirmation malfunction occurs
. When a HUB class USB storage
device is connected
Disconnect the USB storage device/iPod®
and check it.

Audio control buttons (if
equipped)
These buttons are located on the spokes
of the steering wheel. They allow the
driver to control audio functions without
taking his/her hands off the steering
wheel.

& MODE button

Models without Hands-free system
