Starting and operating

the “AUTO [+]” mode. After setting the
mode, “
” on the combination meter
illuminates.

Pull the control switch rearward to select
the “AUTO [−]” mode. After setting the
mode, “
” on the combination meter
illuminates.
When the “AUTO [+]” mode is selected,
pull the control switch rearward to change
to the “AUTO” mode. When the “AUTO
[−]” mode is set, push the control switch
forward to change to the “AUTO” mode.

& Manual mode

In the manual mode, you can use the
center differential control switch to adjust
the initial LSD torque as desired. When
this mode is selected, the “AUTO” indicator light on the combination meter turns
off.

7-21

! Center differential control switch
and indicator light

The control switch is located beside the
parking brake lever. By pushing the
control switch forward or pulling it rearward, it is possible to change the initial
LSD torque.
The center differential indicator lights on
the combination meter give six levels of
indication. The indicator lights and control
switch are linked; when the switch is
pushed or pulled to ch
