3-28

Instruments and controls

! Vehicle Dynamics Control OFF indicator light (yellow)
. This light illuminates when the Vehicle
Dynamics Control OFF switch is pressed
(except WRX STI).
. This light illuminates when the Vehicle
Dynamics Control mode switch is pressed
for more than 2 seconds (WRX STI).
. The light illuminates when the Vehicle
Dynamics Control system is deactivated.

! Traction Control OFF indicator light
(green – WRX STI)
. The light illuminates when the Vehicle
Dynamics Control mode switch is pressed
briefly.
. The light illuminates when the traction
control system is deactivated.

& Security indicator light

NOTE
. The light may remain illuminated for
a while after the engine has been
started, especially in cold weather. This
does not indicate the existence of a
problem. The light should turn off as
soon as the engine has warmed up.
. The indicator light illuminates when
the engine has developed a problem
and the CHECK ENGINE warning light/
malfunction indicator lamp is on.
The Vehicle Dynamics Control system is
probably malfunctioning under the following condition. Have your vehicle checked
at a SUBARU dealer as soon as possible.
. The light does not turn off even after
the lapse of several minutes (the engine
has warmed up) after the engine has
started.

Non-turbo models

Turbo models

The security indicator light deters potential
thieves by indicating that the vehicle is
equipped with an immobilizer system. It
begins flashing (approximately once every
3 seconds) approximately 60 seconds
after the ignition switch is turned from the
“ON” position to the “Acc” or “LOCK”
position or immediately after the key is
pulled out.
If the security indicator light does not flash,
the immobilizer system may not be functioning properly. If this occurs, contact
your SUBARU dealer as soon as possible.
In case an unauthorized key is used (e.g.,
an imitation key), the security indicator
light illuminates.
