3-24

Instruments and controls

& ABS warning light
The ABS warning light illuminates when
the ignition switch is turned to the “ON”
position and turns off after approximately 2
seconds.
This is an indication that the ABS system
is working properly.

CAUTION
If the warning light behaves as
follows, the ABS system may not
work properly.
When the warning light is on, the
ABS function shuts down; however,
the conventional brake system continues to operate normally.
. The warning light does not illuminate when the ignition switch
is turned to the “ON” position.
. The warning light illuminates
when the ignition switch is
turned to the “ON” position, but
it does not turn off even when the
vehicle speed exceeds approximately 8 mph (12 km/h).
. The warning light illuminates during driving.
If any of these conditions occur,
have the ABS system repaired at
the first available opportunity by

your SUBARU dealer.
With a vehicle equipped with an EBD
system, the ABS warning light illuminates
together with the brake system warning
light if the EBD system malfunctions. For
further details of the EBD system malfunction warning, refer to “Brake system
warning light” F3-24.

NOTE
If the warning light behavior is as
described in the following, the ABS
system may be considered normal.
. The warning light illuminates right
after the engine is started but turns off
immediately, remaining off.
. The warning light remains illuminated after the engine has been started,
but it turns off when the vehicle speed
reaches approximately 8 mph (12
km/h).
. The warning light illuminates during
driving, but it turns off immediately and
remains off.
When driving with an insufficient battery
voltage such as when the engine is jump
started, the ABS warning light may illuminate. This is due to the low battery voltage
and does not indicate a malfunction.
When the battery becomes fully charged,
the light will turn off.

& Brake system
warning light

WARNING
. Driving with the brake system
warning light on is dangerous.
This indicates your brake system
may not be working properly. If
the light remains illuminated,
have the brakes inspected by a
SUBARU dealer immediately.
. If at all in doubt about whether
the brakes are operating properly, do not drive the vehicle.
Have your vehicle towed to the
nearest SUBARU dealer for repair.
This light has the following three functions.
! Parking brake warning
The light illuminates with the parking
brake applied while the ignition switch is
in the “ON” position. It turns off when the
parking brake is fully released.
! Brake fluid level warning
This light illuminates when the brake fluid
level has dropped to near the “MIN” level
of the brake fluid reservoir with the ignition
switch in the “ON” position and with the
parking brake fully released.
