Instruments and controls

& Speedometer
The speedometer shows the vehicle
speed.

3-13

The display can be switched as shown
below by pressing the trip knob.

& Odometer/Trip meter

*: “ ” or “
” cannot be displayed when
the ignition switch is in the “ON” position.
To change the current setting, press the
trip knob for at least 2 seconds.
: Activated
: Deactivated

NOTE
Your vehicle’s initial movement setting
of the meter/gauge needles has been
set for activation “ ” at the time of
shipment from the factory.

1)

Trip knob

*: “ ” or “
” cannot be displayed when
the ignition switch is in the “ON” position.
For the “ ” or “
” indication, refer to
“Canceling the function for meter/gauge
needle movement upon turning on the
ignition switch” F3-12.

This meter displays the odometer and two
trip meters when the ignition switch is in
the “LOCK”, “Acc” or “ON” position.
If you press the trip knob when the ignition
switch is in the “LOCK” position, the
odometer/trip meter will light up. It is
possible to switch the indications while
the odometer/trip meter is lit up. If you do
not press the trip knob within 10 seconds
of illumination of the odometer/trip meter,
the odometer/trip
