Instruments and controls

& Tachometer

even if the fuel tank contains fuel.

The tachometer shows the engine speed
in thousands of revolutions per minute.

The gauge may move slightly during
braking, turning or acceleration due to fuel
level movement in the tank.
If you press the trip knob while the ignition
switch is in the “LOCK” or “Acc” position,
the fuel gauge will light up and indicate the
amount of fuel remaining in the tank.
If, while the fuel gauge is indicating the
amount of fuel remaining in the tank, you
(a) do not press the trip knob for 10
seconds or (b) open and close the driver’s
door, the fuel gauge indication will turn off.

CAUTION
Do not operate the engine with the
pointer of the tachometer in the red
zone. This may cause severe damage to the engine.

& Fuel gauge

NOTE

3-9

This indicates that the fuel filler door
(lid) is located on the right side of the
vehicle.
! Low fuel warning light
The low fuel warning light illuminates
when the tank is nearly empty [approximately 2.6 US gal (10.0 liters, 2.2 Imp
gal)].
It only operates when the ignition switch is
in the “ON” position.

NOTE
This light does not turn off unless the
tank is replenished up to an internal
fuel quantity of approximately 4.0 US
gal (15 liters, 3.3 Imp gal).

CAUTION
Promptly put fuel in the tank whenever the low fuel warning light
illuminates. Engine misfires as a
result of an empty tank could cause
damage to the engine.
1)

Low fuel warning light

The fuel gauge shows the approximate
amount of fuel remaining in the tank.
When the ignition switch is in the “LOCK”
or “Acc” position, the fuel gauge shows “E”

You will see the “
gauge meter.

” sign in the fuel
– CONTINUED –
