Keys and doors

“Disarming the system” F2-17.
2. Sit in the driver’s seat and shut all
doors (and the rear gate if your vehicle is a
5-door).
3. Turn the ignition switch to the “ON”
position.
4. Hold down the REAR (UNLOCK) side
of the driver’s power door locking switch,
open the driver’s door within the following
1 second, and wait 10 seconds without
releasing the switch. The setting will then
be changed as follows.
If the system was previously activated:
The odometer/trip meter screen displays
“AL oF” and the horn sounds twice,
indicating that the system is now deactivated.
If the system was previously deactivated:
The odometer/trip meter screen displays
“AL on” and the horn sounds once,
indicating that the system is now activated.

NOTE
You may have the above setting
change done by your SUBARU dealer.

2-15

& If you have accidentally triggered the alarm system
! To stop the alarm
Do any of the following operations:
. Press any button on the remote transmitter.
. Turn the ignition switch to the “ON”
position.

NOTE
Only registered keys will stop the
alarm. If the immobilizer transponder
is not registered, the alarm will not
stop.

: Press to Arm the system.
: Press to Disarm the system.

& Arming the system
! To arm the system using remote
transmitter
1. Close all windows.
2. Remove the key from the ignition
switch.
3. Open the doors and get out of the
vehicle.
4. Make sure that the engine hood (and
the trunk lid on the 4-door) are locked.
5. Close all doors (and the rear gate on
the 5-door).

Turbo models

– CONTINUED –
