Child Restraint Systems 71 |
||||||||||
|
system.
If it is hard to install the child restraint system because the anchorage cover returns to the original position, press the anchorage cover to the seat cushion until it is flat.
3. If the child restraint system makes contact with the head restraint of the rear seating position where the child restraint system is to be installed, perform the following procedure. – Except rear center seat: Remove the head restraint.
– Rear center seat: Raise the head restraint to the extended position. If the child restraint system still makes contact, remove the head restraint.
For details, refer to“ Head Restraint
|
Adjustment” FP41. |
CAUTION
Store the removed head restraint in the trunk. Do not place the head restraint in the passenger compartment to prevent it from being thrown around in the passenger compartment in a sudden stop or a sharp turn.
4. While following the instructions supplied by the child restraint system manufacturer, connect the lower hooks onto the lower anchorages located at“” marks on the bottom of the rear seatback. When the hooks are connected, make sure the adjacent seatbelts are not caught.
|
5. If your child restraint system is a flexible attachment type( which uses tether belts), push the child restraint system into the seat cushion and pull both left and right lower tether belts up to secure the child restraint system by taking up the slack in the belt.
6. Latch the top tether hook onto the tether anchorage that is located on the rear shelf and tighten the top tether firmly. For additional instructions, refer to“ Top Tether Anchorages” FP72.
– CONTINUED –
|
1
Seat, Seatbelt and SRS Airbags
|
