Driver Monitoring System 357 |
|||||
|
starts user recognition. The user recognition screen may not appear when the door is opened in some cases, such as when only a short time has passed after the push-button ignition switch was turned OFF. In such cases, user recognition starts when the door is closed however the user recognition screen does not appear.
2. Sit in the driver’ s seat and face forward for a few moments.
3. When user recognition is completed, the Hello screen appears on the combination meter display.
At this time, climate control settings, combination meter display basic screen, center information display basic screen, and customization settings all change
|
based on the user information.
NOTE
. When a center information display operation switch is pressed, the user recognition screen is canceled, however user recognition continues.
. If user recognition fails, perform recognition again following the instructions, refer to“ When a user is not recognized” FP357.
. User recognition is not performed while driving.
! When a user is not recognized s07bp0402
In the following case, user recognition may not be possible and“ User recognition stopped.” may be displayed.
. There is an object blocking the camera.
Remove the obstacle and follow the reference procedure to perform user recognition again.
Refer to“ Driver Monitoring System” FP207.
|
1 Camera
NOTE
. User recognition may not be possible when there is dirt or fingerprints on the user recognition camera. To clean, either wipe using a soft cloth or else wipe gently using a moistened cloth that has been thoroughly wrung out.
. When the synchronized user function is turned OFF, manual repeat facial scan is not possible.
& Registering and Deleting a User s07bp05
Users can be registered in the Driver Monitoring System, and registered users can be deleted. For the user registration
|
7
Starting and Operating
|
||
– CONTINUED – |
