Parking Brake Stroke( MT Models) 435 |
||||||
|
& Breaking-In of New Brake Pads and Linings( MT Models) s11at01
When replacing the brake pad or lining, use only genuine SUBARU parts. After replacement, the new parts must be broken in as follows.
! Brake pad and lining s11at0101
While maintaining a speed of 30 to 40 mph( 50 to 65 km / h), step on the brake pedal lightly. Repeat this five or more times.
! Parking brake lining s11at0102
1. Drive the vehicle at a speed of approximately 22 mph( 35 km / h).
2. With the parking brake release button pushed in, pull the parking brake lever SLOWLY and GENTLY( pulling with a force of approximately 33.7 lbf [ 150 N, 15.3 kgf ]).
3. Drive the vehicle for approximately 220 yards( 200 meters) in this condition.
4. Wait 5 to 10 minutes for the parking brake to cool down. Repeat this procedure.
5. Check the parking brake stroke. If the parking brake stroke is out of the specified range, adjust it by turning the adjusting nut located on the parking brake lever.
|
Parking brake stroke: 7 – 8 notches / 45 lbf( 200 N, 20.4 kgf)
WARNING
A safe location and situation should be selected for break-in driving.
CAUTION
Pulling the parking brake lever too forcefully may cause the rear wheels to lock. To avoid this, be certain to pull the lever up slowly and gently.
|
11-21. Parking Brake Stroke( MT Models) |
s11au
Check the parking brake stroke according to the maintenance schedule in the“ Warranty and Maintenance Booklet”.
|
Maintenance and Service
11
|
