A 4.2-inch display models B 12.3-inch display models 1 Normal operating range
If the radiator cooling fan does not operate even when the engine coolant temperature gauge exceeds the normal operating range, the cooling fan circuit may be defective. Refer to“ Engine Coolant Temperature Gauge” FP148.
Check the fuse and replace it if necessary. Refer to“ Fuses” FP450. If the fuse is not blown, have the cooling system checked by your SUBARU dealer.
If the frequent addition of coolant is necessary between vehicle service visits, it is recommended that you have your vehicle inspected by an authorized SUBARU dealer to check for leaks, da-
|
1“ FULL” level mark 2“ LOW” level mark
Check the coolant level, such as at fuel stops.
1. Check the coolant level on the outside of the reservoir while the engine is cool.
2. If the level is close to or lower than the“ LOW” level mark, add coolant up to the“ FULL” level mark. If the reserve tank is empty, remove the radiator cap and refill coolant up to just below the filler neck as shown in the following illustration.
|
1 Fill up to this level.
3. After refilling the reserve tank and the radiator, reinstall the cap and check that the rubber gaskets inside the radiator cap are in the proper position.
|
Maintenance and Service
11
|
||
– CONTINUED – |
