Flat Tires 391 |
||||||
|
NOTE
New sealant and replacement parts can be purchased from your authorized repair shop or SUBARU dealer, and they should also be installed into the kit by a specialist. Empty sealant bottles and replacement parts must be returned to your SUBARU dealer or disposed of in compliance with local waste disposal regulations.
! Technical data of air compressor s09ac0303
Line voltage DC 12 V Operating voltage DC 10 – 15 V Amperage
Max. 10 A
|
& Tire Pressure Monitoring System( TPMS)( U. S.-Spec. Models) s09ac02 |
Low tire pressure warning light
The tire pressure monitoring system provides the driver with the warning message indicated by sending a signal from a sensor that is installed in each wheel when tire pressure is severely low.
The tire pressure monitoring system will activate only when the vehicle is driven. Also, this system may not react immediately to a sudden drop in tire pressure( for example, a blow-out caused by running over a sharp object).
|
WARNING
. If the low tire pressure warning light illuminates while driving, never brake suddenly. Instead, perform the following procedure. Otherwise an accident involving serious vehicle damage and serious personal injury could occur.
( 1) Keep driving straight ahead while gradually reducing speed.
( 2) Slowly pull off the road to a safe place.
( 3) Check the pressure for all four tires and adjust the pressure to the COLD tire pressure shown on the tire inflation pressure label on the door pillar on the driver’ s side.
If this light still illuminates while driving after adjusting the tire pressure, a tire may have significant damage and a fast leak that causes the tire to lose air rapidly. If you have a flat tire, refer to“ Flat Tires” FP379.
. When a replacement tire is mounted or a wheel rim is replaced without the original pressure sensor / transmitter being
|
In Case of Emergency
9
|
||
– CONTINUED – |
