Driver Monitoring System 357 |
|||
|
2. Sit in the driver’ s seat and face forward for a few moments.
3. When user recognition is completed, the Hello screen appears on the combination meter display.
At this time, climate control settings, combination meter display basic screen, center information display basic screen, and customization settings all change based on the user information.
NOTE
. When a center information display operation switch is pressed, the user recognition screen is canceled, however user recognition continues.
|
. If user recognition fails, perform recognition again following the instructions, refer to“ When a user is not recognized” FP357.
. User recognition is not performed while driving.
! When a user is not recognized s07bp0402
In the following case, user recognition may not be possible and“ User recognition stopped.” may be displayed.
. There is an object blocking the camera.
Remove the obstacle and follow the reference procedure to perform user recognition again.
Refer to“ Driver Monitoring System” FP207.
1 Camera
|
NOTE
. User recognition may not be possible when there is dirt or fingerprints on the user recognition camera. To clean, either wipe using a soft cloth or else wipe gently using a moistened cloth that has been thoroughly wrung out.
. When the synchronized user function is turned OFF, manual repeat facial scan is not possible.
& Registering and Deleting a User s07bp05
Users can be registered in the Driver Monitoring System, and registered users can be deleted. For the user registration and delete procedures, refer to“ Driver Monitoring System” FP207.
NOTE
. When the Driver Monitoring System OFF indicator, Driver Monitoring System temporary stop indicator, or Driver Monitoring System warning is illuminated, the following items cannot be selected. – Register User – Delete User – Delete All Users
. User information can also be deleted by resetting the center information
– CONTINUED –
|
7
Starting and Operating
|
