334
BSD / RCTA
& BSD / RCTA Warning Indicator s07bm04
! System malfunction s07bm0403
1 BSD / RCTA malfunction message 2 At first, this message will appear 3 Then this message will appear 4 BSD / RCTA warning indicator
This display appears when a malfunction occurs in the system. Contact a SUBARU dealer and have the system inspected.
& To Turn On / Off the BSD / RCTA s07bm09
BSD / RCTA OFF indicator
To turn the BSD / RCTA system on and off, operate the center information display. Refer to“ Car settings” FP200.
When the BSD / RCTA system is turned OFF, the BSD / RCTA OFF indicator on the combination meter will illuminate.
NOTE
. If you turn off the BSD / RCTA, some EyeSight functions will also be deactivated. For details, refer to the Owner’ s Manual supplement for the EyeSight system.
. If the ignition switch is turned to the“ OFF” position, the last known status of the system is maintained. For example, if the ignition switch is turned to the“ OFF” position with the BSD / RCTA deactivated, the BSD / RCTA remains deactivated the next time the ignition switch is turned to the“ ON” position.
& Certification for the BSD / RCTA s07bm06
. The U. S. and other FCC compliant countries
FCC ID: OAYSRR3A
CAUTION
FCC WARNING
Changes or modifications not expressly approved by the party responsible for compliance could void the user’ s authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:( 1) This device may not cause harmful interference, and( 2) this device must accept any interference received, including interference that may cause undesired operation.
