322
Rear View Camera
|
! To reactivate s07au0202
To reactivate the Hill start assist system, repeat steps 1 to 8. When the Hill start assist system is activated, the Hill start assist OFF indicator light turns off.
& Hill Start Assist Warning Light / Hill Start Assist OFF Indicator Light( MT Models)
s07au01
Refer to“ Hill Start Assist Warning Light / Hill Start Assist OFF Indicator Light( MT Models)” FP161.
|
7-18. Rear View Camera |
|
|
s07br |
and mirrors, and move backward at a slow speed. Moving backward only by checking the rear view image from the camera could cause an accident.
. Do not disassemble or modify the camera, switch or wiring. If smoke comes out or you smell a strange odor, stop using the rear view camera immediately. Contact your SUBARU dealer for an inspection. Continued use may result in accident, fire or electric shock.
|
A rear view camera is attached to the trunk lid. When the ignition switch is in the“ ON” position and the select lever is set to“ R”, the rear view camera automatically displays the rear view image behind the vehicle on the center information display.
WARNING
. Since the rear view camera uses a wide-angle lens, the image on the monitor is different from the actual view in terms of distance.
. Since the range of the image on the monitor is limited, always check the rear view and the surrounding area with your eyes
CAUTION
. When washing your vehicle with a high-pressure washer, do not allow water to touch the camera directly. Entry of water in the camera lens may result in condensation, malfunction, fire or electric shock.
. Since the camera is a precision device, do not subject it to strong impacts. Otherwise, malfunction, fire or electric shock may occur.
. If mud or snow sticks to or is frozen on the camera, you must be very careful when removing it.
