Braking 303 |
|||||||||
|
module may be heard. This is not a malfunction.
. The brake pedal was operated.. The driver’ s door was opened.. The EyeSight function was activated.
. Several minutes have passed after the engine stopped.
|
! Supplemental booster function when pressure fails s07ak020701
If there is a malfunction in the braking system, the power for the braking will be stored by controlling the hydraulic pressure of the VDC system.
When the brake pedal is depressed while the supplemental booster function is operating, an operation sound and brake pedal vibration may be generated.
! Brake assist system
WARNING
s07ak0203
Do not be overconfident about the brake assist. It is not a system that brings more braking ability to the vehicle beyond its braking capability. Always use the utmost care when driving regarding vehicle speed and safe distance.
|
CAUTION
When you need to brake suddenly, continue depressing the brake pedal strongly to bring the effect of the brake assist.
Brake assist is a driver assistance system. It assists the brake power when the driver cannot depress the brake pedal strongly and the brake power is insufficient.
Brake assist generates the brake power according to the speed at which the driver depresses the brake pedal.
NOTE
When you depress the brake pedal strongly or suddenly, the following phenomena occur. However, even though these occur, they do not indicate any malfunctions, and the brake assist system is operating properly.
. You might feel that the brake pedal is applied by lighter force and generates a greater braking force.
. You might hear the sound of ABS operating from the engine compartment.
|
& Disc Brake Pad Wear Warning Indicators s07ak03 |
The disc brake pad wear warning indicators on the disc brakes give a warning noise when the brake pads are worn.
If a squeaking or scraping noise is heard from the disc brakes while braking, immediately have your vehicle inspected by the nearest SUBARU dealer.
|
7
Starting and Operating
|
||||
– CONTINUED – |
