Center Information Display( CID)
& Basic Screens
! Touch screen s03bs05
s03bs0501
1 HOME icon( Refer to“ HOME icon” FP194.)
2 Status bar( Refer to“ Status bar” FP188.)
3 Information bar( Refer to“ Information bar” FP188.)
4 Main screen( Refer to“ Main screen” FP194.)
5 Manage device icon( Refer to the separate navigation / audio Owner’ s Manual)
6 Driver profiles icon( Refer to“ Driver profiles icon” FP194.)
7 Climate control screen( Refer to“ Climate control screen” FP194.)
8 Auto Vehicle Hold( AVH) ON / OFF icon( CVT models)( Refer to“ Auto Vehicle Hold( AVH) ON / OFF icon( CVT models)” FP191.)
9 Car settings icon( Refer to“ Car settings icon” FP191.)
While the ignition switch is in the“ ACC” or“ ON” position, the touch panel will activate.
! Status bar s03bs050101
The outside temperature and clock are displayed on the status bar.
NOTE
. The outside temperature indicator shows the temperature around the sensor. However, the temperature may not be indicated correctly or the update may be delayed in the following conditions. – While parking or driving at low speeds – When the outside temperature changes suddenly( example: when going in and out of an underground parking area or when passing through a tunnel)
– When starting the engine after being parked for a certain period of time
. You can set the temperature to be displayed in Celsius or Fahrenheit. For details, refer to“ General settings” FP195.
. The clock can be displayed in either 12-hour display or 24-hour display. For details, refer to“ General settings” FP195.
. Touch the clock on the status bar to display the clock setting screen. Refer to“ Clock” FP212.
. For details about Bluetooth device information, refer to the navigation / audio Owner’ s Manual.
! Information bar s03bs050102
Swipe the information bar or touch or on the information bar to switch the item displayed.
