144
Push-Button Ignition Switch
3-1 . Push-Button Ignition Switch
& Safety Precautions
Refer to “ Safety Precautions ” FP107 . s03bg
s03bg04
& Operating Range for Push- Button Start System s03bg01
1 Antennas 2 Operating range
NOTE
. If the access key fob is not detected within the operating range of the antennas inside the vehicle , the push-button ignition switch and the engine start cannot be operated .
. Even when the access key fob is outside the vehicle , if it is placed too close to the glass , it may be possible to switch the power or to start the engine .
. Do not leave the access key fob in the following places . It may become impossible to operate the pushbutton ignition switch and the engine start . – On the instrument panel – On the floor – Inside the glove box – Inside the door trim pocket – On the rear seat – On the rear shelf – Inside the trunk
. When operating the push-button ignition switch or starting the engine , if the access key fob battery is discharged , perform the procedure described in “ Access Key Fob – If Access Key Fob Does Not Operate Properly ” FP401 . In such a case , replace the battery immediately . Refer to “ Replacing Battery of Access Key Fob ” FP457 .
& Switching Power Status
1 Operation indicator 2 Push-button ignition switch s03bg02
The power status is switched every time the push-button ignition switch is pressed .
1 . Carry the access key fob , and sit in the driver ’ s seat .
2 . Make sure the select lever is in neutral ( MT models ) or the select lever in the “ P ” position ( CVT models ).
3 . Press the push-button ignition switch without depressing the clutch pedal ( MT models ) or brake pedal ( CVT models ). Every time the button is pressed , the power is switched in the sequence of “ OFF ”, “ ACC ”, “ ON ” and “ OFF ”. When the engine is stopped and the push-button ignition switch is
