92
SRS Airbag( Supplemental Restraint System Airbag)
! Examples of the types of accidents in which the driver’ s / driver’ s and front passenger’ s SRS frontal airbag( s) are not designed to deploy in most cases s01ah021104
The driver’ s and front passenger’ s SRS frontal airbags are not designed to deploy in most of the following cases.
. If the vehicle is struck from the side or from behind
. If the vehicle rolls onto its side or roof
. If the vehicle is involved in a low-speed frontal collision
concrete wall in immediate succession, once either or both of the driver’ s and front passenger’ s SRS frontal airbags is / are activated on the first impact, it / they will not be activated on the second impact.
& SRS Side Airbag and SRS Curtain Airbag s01ah03
1 First impact 2 Second impact
In an accident where the vehicle is impacted more than once, the driver’ s and / or front passenger’ s SRS frontal airbag( s) will deploy only once on the first impact.
Example: In the case of a double collision, first with another vehicle, then against a
! SRS side airbag s01ah0302
The SRS side airbag is stored in the door side of each front seat seatback, which bears an“ SRS AIRBAG” mark.
In a moderate to severe side impact collision, the SRS side airbag on the impacted side of the vehicle deploys between the occupant and the door panel and supplements the seatbelt by reducing the impact on the occupant’ s chest and
