risk of serious neck injury in the event that the vehicle is struck from the rear . Therefore , when the head restraints are removed , all head restraints must be reinstalled properly to protect vehicle occupants .
. The vehicle should not be operated until the head restraints are installed in the proper position .
! Rear windows side seating position s01ac0301
|
To install :
Install the head restraint into the holes that are located on the top of the seatback until the head restraint locks . Press and hold the release button to lower the head restraint .
After installing the head restraint , make sure it is securely locked .
NOTE
When the head restraint cannot be pulled out or installed due to insufficient clearance between the head restraint and the roof , tilt the seat and then perform the installation and removal tasks .
|
! Rear center seating position |
1 Incorrect ( retracted position ) 2 Correct ( extended position ) |
s01ac0302 |
CAUTION |
