Front Seats 35 |
||||||||||
|
ble in the following ways .
! Head restraint height adjustment s01aa0401
|
1 Head restraint 2 Release button 3 Remove button
To release : . Lowermost to the 1st step Pull the head restraint up to the 1st step .
To raise : . 1st step to the 3rd step
Pull the head restraint up while pressing the release button on the top of the seatback .
To lower :
Push the head restraint down while pressing the release button on the top of the
|
seatback . To remove :
Use a key or other hard , pointed object to press the remove button , then pull out the head restraint .
To install :
Push the head restraint into the holes on the top of the seatback until it locks .
Each head restraint should be adjusted so that the center of the head restraint is closest to the top of the occupant ’ s ears .
NOTE
It is not possible to remove or install the head restraint without reclining the front seatback . Reclining the front seatback and then remove or install the head restraint .
|
! Head restraint angle adjustment s01aa0402 |
The angle of the head restraint can be adjusted in several steps . While maintaining a suitable driving posture , adjust the head restraint to a position where the back of your head is as close to the head restraint as possible .
To tilt :
Tilt the head restraint by hand to the preferred position . A click will be audible when the head restraint is locked .
To return :
Tilt the head restraint once as far forward as it can go . The head restraint will automatically return to the fully upright position . Then , adjust the head restraint again to the preferred angle .
|
1
Seat , Seatbelt and SRS Airbags
|
