Flat Tires 395 |
||||||
|
NOTE
New sealant and replacement parts can be purchased from your authorized repair shop or SUBARU dealer , and they should also be installed into the kit by a specialist . Empty sealant bottles and replacement parts must be returned to your SUBARU dealer or disposed of in compliance with local waste disposal regulations .
! Technical data of air compressor s09ac0303
Line voltage DC 12 V Operating voltage DC 10 – 15 V Amperage
Max . 10 A
|
& Tire Pressure Monitoring System ( TPMS ) ( U . S . -Spec . Models ) s09ac02 |
Low tire pressure warning light
The tire pressure monitoring system provides the driver with the warning message indicated by sending a signal from a sensor that is installed in each wheel when tire pressure is severely low .
The tire pressure monitoring system will activate only when the vehicle is driven . Also , this system may not react immediately to a sudden drop in tire pressure ( for example , a blow-out caused by running over a sharp object ).
|
WARNING
. If the low tire pressure warning light illuminates while driving , never brake suddenly . Instead , perform the following procedure . Otherwise an accident involving serious vehicle damage and serious personal injury could occur .
( 1 ) Keep driving straight ahead while gradually reducing speed .
( 2 ) Slowly pull off the road to a safe place .
( 3 ) Check the pressure for all four tires and adjust the pressure to the COLD tire pressure shown on the tire inflation pressure label on the door pillar on the driver ’ s side .
If this light still illuminates while driving after adjusting the tire pressure , a tire may have significant damage and a fast leak that causes the tire to lose air rapidly . If you have a flat tire , refer to “ Flat Tires ” FP383 .
. When a replacement tire is mounted or a wheel rim is replaced without the original pressure sensor / transmitter being
|
In Case of Emergency
9
|
||
– CONTINUED – |
