Reverse Automatic Braking ( RAB ) System
& Automatic Braking Function Operation s07bn08
! Object close behind warning s07bn0801
Long proximity alert ( object detected ) 1 Green : 35 to 59 in ( 90 to 150 cm )
Short proximity alert ( approaching the object closer )
1 Orange : 20 to 28 in ( 50 to 70 cm )
Medium proximity alert ( approaching the object )
1 Yellow : 28 to 35 in ( 70 to 90 cm )
Closest proximity alert ( too close to the object ) 1 Red : 20 in ( 50 cm ) or less
Automatic braking warning 1 Warning message
If the system determine the risk of collision with the object . Short warning beeps or continuous warning beeps will sound and either strong automatic braking or torque control will be applied to prevent collision .
At this time , a warning message is also displayed on the combination meter display ( color LCD ).
