BSD / RCTA 349 |
|||
|
appear .
If the indicator remains displayed for a prolonged time , have the system inspected at a SUBARU dealer .
! System temporary stops due to reduced radar sensitivity s07bm0802
|
& BSD / RCTA Warning Indicator s07bm04
! System malfunction s07bm0403
|
& To Turn On / Off the BSD / RCTA s07bm09 |
|
|
BSD / RCTA OFF indicator
To turn the BSD / RCTA system on and off , operate the center information display . Refer to “ Car settings ” FP198 ( 11.6-inch display models ) or “ Car Settings icon ” FP211 ( dual 7.0-inch display models ).
When the BSD / RCTA system is turned OFF , the BSD / RCTA OFF indicator on the combination meter display ( color LCD ) will illuminate .
|
|||
|
1 BSD / RCTA temporary stop message due to reduced radar sensitivity
2 BSD / RCTA OFF indicator
This display appears when the detectability of the radar sensors is reduced . Once the condition is corrected , the system will recover from the temporary stop condition and the indicator will disappear .
|
1 BSD / RCTA malfunction message 2 At first , this message will appear 3 Then this message will appear 4 BSD / RCTA warning indicator
This display appears when a malfunction occurs in the system . Contact a SUBARU dealer and have the system inspected .
|
7
Starting and Operating
|
|
If the indicator remains displayed for a prolonged time , have the system inspected at a SUBARU dealer . |
|||
– CONTINUED – |
