BSD / RCTA 347 |
|||
|
neighboring lane .
& BSD / RCTA Approach Indicator Light / Warning Buzzer s07bm03
While the BSD / RCTA is active , the following item ( s ) will operate to alert the driver :
. The BSD / RCTA approach indicator light ( when there are vehicles in the neighboring lanes ).
. The BSD / RCTA approach indicator light and warning buzzer ( when a vehicle is approaching from the left or right side while your vehicle is reversing )
! BSD / RCTA approach indicator light s07bm0301
BSD / RCTA approach indicator light
|
It is mounted on each side of the outside mirrors .
The indicator light will illuminate when a vehicle approaching from behind is detected .
The indicator light will flash to warn the driver of dangers under the following conditions .
. While the indicator light is illuminating , if the turn signal lever is operated toward the side in which this light turned on
. When reversing the vehicle while the system detects a vehicle approaching from either side
! BSD / RCTA approach indicator light dimming function s07bm030101
When the headlights are turned on , the brightness of the BSD / RCTA approach indicator light will be reduced .
NOTE
. You may have difficulty seeing the BSD / RCTA approach indicator light under the following conditions . – When sunlight shines directly on it
– When the headlight beams from a vehicle traveling behind shines directly on it
. While the illumination brightness control dial is in the fully upward
|
position , even if the headlights are turned on , the brightness of the BSD / RCTA approach indicator light will not be reduced . For details about the illumination brightness control dial , refer to “ Illumination Brightness Control ” FP151 .
! BSD / RCTA approach warning buzzer ( only when reversing ) s07bm0302
A warning buzzer sounds along with flashing of the BSD / RCTA approach indicator light to warn the driver of dangers .
The setting of the warning buzzer volume can be changed by operating the center information display . For details , refer to “ Car settings ” FP198 ( 11.6-inch display models ) or “ Car Settings icon ” FP211 ( dual 7.0-inch display models ).
! Safety tips regarding the BSD / RCTA approach indicator light / warning buzzer s07bm0303
. In the following cases , operation of the BSD / RCTA approach indicator light and the warning buzzer may be delayed or the system may fail to issue these warnings . – When a vehicle moves to the neighboring lane from a lane next to the neighboring lane
– CONTINUED –
|
7
Starting and Operating
|
