BSD / RCTA 345 |
||||||||
. An icon appears on the center information display . |
! Limitations of the detectability of RCTA s07bm010301
Since the detectability of RCTA is limited , the RCTA may not operate properly in angled parking .
Example 1 1 The detection range of the radar sensors
2 Area out of detection range of the radar sensors
A Vehicle that may not be detected B Parked vehicle
WARNING
An approaching vehicle ( A ) may not be detected because the detection
|
range is limited by the parked vehicle ( B ). Always be sure to check the surroundings with your eyes when reversing the vehicle . |
Example 2 1 The detection range of the radar sensors C Vehicle that may be detected
NOTE
The system may detect that a vehicle ( C ) is passing in front of your vehicle . Always be sure to check the surroundings with your eyes when reversing the vehicle .
|
& System Operation
s07bm02
! Operating conditions s07bm0201
The BSD / RCTA will operate when all of the following conditions are met .
. The ignition switch is in the “ ON ” position .
. The BSD / RCTA warning indicator and BSD / RCTA OFF indicator are turned off .
. The vehicle is driven at speeds above 7 mph ( 12 km / h ) ( except when reversing ).
. The select lever is in the “ R ” position ( RCTA only ).
The BSD / RCTA will not operate in the following situations .
. The BSD / RCTA OFF indicator appears .
. The vehicle speed is below 6 mph ( 10 km / h ) even when the BSD / RCTA OFF indicator does not appear ( except when reversing ).
NOTE
. In the following cases , the BSD / RCTA will stop operating and the BSD / RCTA warning indicator will appear . – When a malfunction occurs in the system , including the BSD / RCTA approach indicator light
|
7
Starting and Operating
|
|||
– CONTINUED – |
