Continuously Variable Transmission 311 |
||||||||
|
not be moved to the “ P ” position without depressing the brake pedal and pressing the select lever button .
! Shift lock release s07bg0401
If the select lever cannot be operated , turn the ignition switch back to the “ ON ” position , then move the select lever to the “ P ” position with the select lever button pressed and the brake pedal depressed .
If the select lever does not move after performing the above procedure , check and confirm the following and release the shift lock accordingly .
. When the select lever cannot be shifted from “ P ” to “ N ”:
Refer to “ Shift lock release using the shift lock release portion ” FP311 .
. When the select lever cannot be shifted from “ N ” to “ R ” or “ P ”:
Place the ignition switch in the “ ACC ” position , then move the select lever to the “ P ” position with the brake pedal depressed .
If the select lever still does not move , refer to “ Shift lock release using the shift lock release portion ” FP311 .
If the shift lock cannot be released without using the shift lock release button in the above cases , there may be a malfunction
|
in the shift lock system or the vehicle control system .
Contact a SUBARU dealer for an inspection as soon as possible .
! Shift lock release using the shift lock release portion s07bg0402
Perform the following procedure to release the shift lock .
1 . Apply the parking brake and stop the engine .
1 Hole
2 . Turn over the inner trim of the pocket .
|
3 . Remove the grip portion of the screwdriver .
4 . While depressing the brake pedal , insert the screwdriver into the hole , press the shift lock release portion using the screwdriver , and then move
|
7
Starting and Operating
|
|||||
– CONTINUED – |
