State Emission Testing ( U . S . Only ) 289 |
|||||||
|
. Immediately put fuel in the tank whenever the low fuel warning light illuminates . Engine misfires as a result of an empty tank could cause damage to the engine . Continuing to operate your vehicle at an extremely low fuel level may result in a reduction of engine performance .
! If the fuel filler lid cannot be opened s07aa0203
If the fuel filler lid cannot be opened due to a malfunction or a dead battery , it can be opened from the trunk .
|
1 Clip
2 . Remove the clip .
|
7-2 . State Emission Testing ( U . S . Only )
WARNING
s07ab
Only use a four-wheel dynamometer when testing an All-Wheel Drive ( AWD ) model .
Testing of an AWD model must NEVER be performed on a single two-wheel dynamometer . Attempting to do so will result in uncontrolled vehicle movement and may cause an accident or injuries to persons nearby .
|
7 |
||||
1 . Push the access cover at the right-side of the trunk trim . |
3 . Pull the clip to unlock the fuel filler lid . |
CAUTION
. At state inspection time , remember to tell your inspection or service station in advance not to place your SUBARU AWD vehicle on a two-wheel dynamometer . Otherwise , serious transmission damage will result .
. Resultant vehicle damage due to improper testing is not covered under the SUBARU Limited Warranty and is the responsibility of the state inspection program or
|
Starting and Operating |
||||
– CONTINUED – |
