Warning and Indicator Lights 167
& Vehicle Dynamics Control OFF Indicator Light / TRACK Mode Indicator Light s03ae57
The indicator light shows the activated / deactivated conditions as follows .
Indicator light
Activated / deactivated status for each function Vehicle
Traction Control Dynamics ABS
Control system
Turn off Activated Activated Activated
Deactivated Activated Activated
Deactivated Deactivated Activated
For details about the Traction Control and Vehicle Dynamics Control system , refer to “ Vehicle Dynamics Control System ” FP322 .
! Vehicle Dynamics Control OFF indicator light s03ae5702
This light illuminates when the Vehicle Dynamics Control OFF switch is operated to select the TRACK mode or the Vehicle Dynamic Control OFF mode . For details , refer to “ Vehicle Dynamics Control System ” FP322 .
NOTE
. The light may remain illuminated for a while after the engine has been started , especially in cold weather . This does not indicate the existence of a problem . The light should turn off as soon as the engine has warmed up .
. The indicator light illuminates when the engine has developed a problem and the CHECK ENGINE warning light / malfunction indicator light is on .
The Vehicle Dynamics Control system is probably malfunctioning under the following conditions . Have your vehicle checked at a SUBARU dealer as soon as possible .
. The light does not illuminate when the ignition switch is turned to the “ ON ” position .
. The light does not turn off even after the lapse of several minutes ( the engine has warmed up ) after the engine has
– CONTINUED –
3
Instruments and Controls
