Instruments and controls
Gear
position
Period of
time multifunction
button is
pressed
Rear view display
ON/OFF*
More than
3 seconds
Help lines indication ON/OFF
Briefly
Auto-dimming
function ON/OFF*
3 to 6
seconds
Electronic compass display ON/
OFF
6 to 9
seconds
Enter the compass zone setting
mode
9 to 12
seconds
Except
R (reverse)
For precautions about the rear view
camera and the rear view image, refer to
“Rear view camera” F6-21.
! Auto-dimming function
The auto-dimming function is an anti-glare
capability which automatically reduces
glare coming from headlights of vehicles
behind you.
Function
displayed
Briefly
Enter the compass calibration
mode
R (reverse)
*: The setting returns to “ON” as a default
setting every time the ignition switch is turned to
the “ON” position.
! Rear view image display
When the ignition switch is “ON” and the
select lever is set to “R”, the rear view
camera automatically displays the rear
view image behind the vehicle on the
inside mirror.
Also, the following help lines are indicated
as a guide to help you realize the actual
distance from the display.
3-39
1)
2)
3)
4)
5)
Vehicle width line (oblique vertical line)
Approx. 10 feet (3 m) from the bumper
(green horizontal line)
Approx. 6.5 feet (2 m) from the bumper
(green horizontal line)
Approx. 3 feet (1 m) from the bumper
(yellow horizontal line)
Approx. 1.5 feet (0.5 m) from the bumper
(red horizontal line)
By briefly pressing the multifunction button, the auto-dimming function is toggled
on or off. When the auto-dimming function
is on, the auto dimming indicator light
(green) will illuminate.
Even with the mirror in anti-glare mode,
the mirror surface turns bright if the
transmission is shifted into reverse. This
is to ensure good rearward visibility during
reversing.
These help lines are removable. To
remove the help lines, perform the following procedure.
1. Display the rear view image on the
mirror.
2. Press the multifunction button for more
than 3 seconds to remove the help lines.
To display the help lines, press the multifunction button for more than 3 seconds.
– CONTINUED –
