Maintenance and service
11-31
end of the metal support between the
stoppers on the rubber as shown. If the
rubber is not retained properly, the wiper
blade may scratch the windshield.
& Rear window wiper blade
assembly
1. Raise the wiper arm off the rear
window.
3. Align the claws of the metal support
with the grooves in the rubber and slide
the blade rubbe r assembly into the metal
support until it locks.
3. Pull the wiper blade assembly toward
you to remove it from the wiper arm.
& Rear window wiper blade
rubber
2. Turn the wiper blade assembly counterclockwise.
1)
Stopper
4. Be sure to position the claws at the
– CONTINUED –
