Driving tips
has safety chains and that each
chain will hold the trailer’s maximum gross weight. Towing trailers without safety chains could
create a traffic safety hazard if
the trailer separates from the
hitch due to coupling damage or
hitch ball damage.
. Be sure to check the hitch pin
and safety pin for positive locking placement before towing a
trailer. If the ball mount comes off
the hitch receiver, the trailer
could get loose and create a
traffic safety hazard.
. Use only the ball mount supplied
with this hitch. Use the hitch only
as a weight carrying hitch. Do not
use with any type of weight
distributing hitch.
Maximum
gross trailer
weight
8-19
Maximum
gross tongue
weight
Vehicle without cooling kit
2,000 lbs
(906 kg)
200 lbs
(90 kg)
Vehicle with
cooling kit
3,500 lbs
(1,587 kg)
350 lbs
(158 kg)
When you tow a trailer, follow the instructions in “Trailer towing” F8-21.
& Connecting a trailer
1. Remove the receiver cover from the
hitch receiver tube. Then insert the ball
mount into the hitch receiver tube.
3. Insert the safety pin into the hitch pin
securely.
4. Pull the ball mount to make sure it
does not come off the hitch receiver.
The maximum gross trailer weight and
maximum gross tongue weight are indicated in the following table.
2. Insert the hitch pin into the hole on the
hitch receiver tube so that the pin passes
through the ball mount.
1)
2)
Hitch ball installation point
Hooks for safety chains
– CONTINUED –
