1-24
Seat, seatbelt and SRS airbags
! Second-row center seatbelt
WARNING
Fastening the seatbelt with the webbing twisted can increase the risk or
severity of injury in an accident.
When fastening the belt after it is
pulled out from the retractor, especially when inserting the connector’s tongue plate into the mating
buckle (on right-hand side), always
check that the webbing is not
twisted.
1)
2)
3)
4)
belt (with the connector’s tongue
plate not fastened to the connector’s buckle on the right-hand side),
it cannot properly restrain the wearer in position in an accident, possibly resulting in serious injury or
death.
Center seatbelt tongue plate
Connector (tongue)
Connector (buckle)
Center seatbelt buckle
WARNING
Be sure to fasten both tongue plates
to the respective buckles. If the
seatbelt is used only as a shoulder
Center seatbelt is stowed in the recess of
the ceiling.
1. Remove the connector (tongue) plate
from the slot located at the front of the
recess by pulling the connector (tongue)
plate rearward.
