Driving tips
ble.
! Total trailer weight
Vehicle without cooling kit
Conditions
8-21
Maximum total trailer weight
When towing a trailer without brakes.
1,000 lbs (453 kg)
When towing a trailer with brakes.
2,000 lbs (906 kg)
When towing a trailer on a long uphill grade
continuously for over 5 miles (8 km) with an
outside temperature of 1048F (408C) or above.
1,000 lbs (453 kg)
Vehicle with cooling kit
Conditions
When towing a trailer without brakes.
When towing a trailer with brakes.
When towing a trailer on a long uphill grade
continuously for over 5 miles (8 km) with an
outside temperature of 1048F (408C) or above.
Maximum total trailer weight
1,000 lbs (453 kg)
3,500 lbs (1,587 kg)
1,750 lbs (794 kg)
Total trailer weight
The total trailer weight (trailer weight plus
its cargo load) must never exceed the
maximum weight shown in the following
table.
– CONTINUED –
