7-10
Starting and operating
transmitter within a few seconds immediately following remote engine start shutdown.
& Pre-heating or pre-cooling
the interior of the vehicle
Before exiting the vehicle, set the temperature controls to the desired setting
and operation. After the system starts the
vehicle, the heater or air-conditioning will
activate and heat or cool the interior to
your setting.
& Service mod e
In service mode, the remote start function
is temporarily disabled to prevent the
system from unexpectedly starting the
engine while being serviced.
! To engage the service mode
Turn the ignition switch to the “ON”
position, depress and hold the brake pedal
then, press and release the “ ” button on
the remote engine start transmitter three
times. The system will pause for 1 second
and then flash the parking lights and honk
the horn three times indicating that the
system is in service mode. When attempting to activate the remote start system
while in service mode, the parking lights
will flash and the horn will honk two times
and will not start.
! To disengage the service mode
Turn the ignition switch to the “ON”
position, depress and hold the brake
pedal, then press and release the “ ”
button on the remote engine start transmitter three times. The system will pause
for 1 second and flash the parking lights
one time indicating that the system has
exited service mode.
NOTE
When taking your vehicle in for service,
it is recommended that you inform the
service personnel that your vehicle is
equipped with a remote engine start
system.
& Remote engine start transmitter programming and programmable feature option
New transmitters can be programmed to
the remote engine start system in the
event that remote engine start transmitters
are lost, stolen or damaged. The remote
engine start system also has one programmable feature that can be adjusted
for user preference.
The remote engine start system can be
programmed to either make an audible
horn chirp upon remote start activation or
not. Remote engine start transmitter programming and feature programming can
be adjusted using the following procedure.
1. Open the driver’s door (the driver’s
door must remain opened throughout the
entire process).
2. Insert the key into the vehicle’s ignition
switch and turn to the “ON” position.
3. Locate the small black programming
button behind the fuse box cover, on the
driver’s side left under the dashboard
panel.
4. Press and hold the black programming
button for 10 to 15 seconds. The horn will
honk and the parking lights will flash three
times to indicate that the system has
entered programming mode. At this point
you can perform either action (step 5 or
step 6).
5. To program a remote transmitter:
press and release the “ ” button on each
transmitter. The horn will honk and the
parking lights will flash one time to indicate
a successful transmitter learn each time
the “ ” button is pressed. You can
program up to eight transmitters.
6. To toggle the Horn Confirmation chirps
ON/OFF: press and release the brake to
toggle the feature. The horn will chirp and
the parking lights will flash one time to
indicate Confirmation Horn Chirps are
“OFF”. The horn will honk and the parking
lights will flash 2 times to indicate Confirmation Horn Chirps are “ON”. Depres-
