2-2 . Charging
93
Locking and unlocking AC charging connector
The AC charging connector will be locked when it is connected to the AC charging inlet , preventing the AC charging cable from being disconnected while charging .
The AC charging connector is locked / unlocked , in connection with the locked / unlocked state of the door , when it is inserted into the AC charging inlet .
Locking and unlocking the AC charging connector
■ Locking the charging connector
If the door is locked while the AC charging connector is inserted into the AC charging inlet , the AC charging connector will be locked . If the door is locked and the AC charging connector is inserted , the connector locks automatically .
■ Unlocking the charging connector
The AC charging connector will be unlocked when the doors are unlocked .
■ AC charging connector lock function
If the AC charging connector is locked / unlocked repeatedly , it may not work temporary due to protect the system by AC charging system . In this case , wait for a while before connecting the AC charging connector to AC charging inlet again .
The AC charging connector lock function does not guarantee that theft of the AC charging cable will be prevented , and is not necessarily
effective for all mischiefs .
■ When the AC charging connector cannot be inserted into the AC charging inlet
Check that the connector lock pin is not extended .
If the connector lock pin is extended , the connector lock is
operating .
Unlock the doors using the smart
key system or wireless remote control and unlock the AC charging connector lock and check that the
connector lock pin is not extended .
■ If the AC charging connector cannot be unlocked
The AC charging connector can be unlocked by operating the emergency release wire .
1 Open the hood . ( �P . 491 ) 2 Pull the emergency release wire .
The AC charging connector is unlocked and can be removed .
2
Electric Vehicle system
