5-4 . Using the driving support systems
377
WARNING
• When the parking space is in a location that is difficult to park in ( too narrow for your vehicle , etc .)
• When images are unclear due
to dirt or snow attached to the camera lens , light being shined into the camera or shadows
• When tire chains or a compact spare tire is installed to the vehicle
• When the doors or back door are not completely closed
• When an arm is held outside of a window
• In inclement weather such as heavy rain or snow
●Make sure to use only standard sized tires , such as those that were installed to the vehicle when it was shipped from the factory . Otherwise , Advanced Park may not operate properly . Also , when the tires have been replaced , the displayed position of the lines or box displayed on the screen may become incorrect . When replacing the tires , contact your SUBARU dealer .
●In situations such as the following , it may not be possible for
the system to provide assistance to a registered parking spot or to operate correctly :
• When the tires are extremely worn or the tire inflation pressure is low
• When carrying a heavy load
• When the vehicle is tilted due to the carried load
• When a heater is installed in the surface of the parking space ( road surface freeze prevention heater )
• When the wheels are misaligned , such after a wheel has
been subjected to a strong impact
• When a pedestrian or passing vehicle is detected during assistance
• When a device , such as a towing hook , bumper protector , bumper trim , bicycle carrier ,
snow plow , etc ., is installed
• When something is incorrectly detected as a parking line ( light , reflections from a building , difference in height on the parking surface , a gutter , painted road lines , redrawn lines , etc .)
If the vehicle deviates greatly from
the set parking space in any situation other than the above , have the vehicle inspected by your
SUBARU dealer .
■ When using Remote control function ( if equipped )
●Remote control function is a function of the Advanced Park system . When using Remote
control function on public roads , be sure to follow all local road traffic laws and regulations .
●Remote control function can
only be used after agreeing to the disclaimer of the smartphone application .
5
Driving
