2-2 . Charging
125
4 Operate “ Start at set time ” screen and select desired
Each time the button is pressed , the charging schedule switches between on and off . time , and then select .
When the charging mode is “ Start at set time ”, set the charging start
time .
When the charging mode is “ Start
and stop at set times ”, also set the charging stop time .
5 When activating the repeated settings , select the desired
day , and then select .
Each time the day is selected , the repeated setting for the selected
day switches between on and off .
When turned on , the check box is highlighted and the charging schedule is repeated on that day . It is possible to turn more than one day
on .
6 After setting operations are complete , press “ Save ”.
The charging schedule is added to the list and an icon is added to the
“ Charging Schedule ” screen .
■ Switching charging schedules between on and off 1 Display the “ Charging Schedule ” screen . ( �P . 123 )
2 Press “ Edit ”. The “ Scheduled Events ” screen will be displayed on the screen .
3 From the items displayed on the screen , press on or off in the row of the charging schedule you wish to change .
If the charging schedule you wish to change is not displayed on the screen , scroll the list up and down to display it .
■ Changing the registered charging schedules
1 Display the “ Charging Schedule ” screen . ( �P . 123 )
2 Press “ Edit ”.
The “ Scheduled Events ” screen will be displayed on the screen .
3 Press “ Edit ” on the “ Events ” screen .
4 From the items displayed on the screen , press “ Edit ” in the row of the charging schedule you wish to change .
• Changing registered items :
Change the desired settings as described starting from step 3 of the “ Registering the charging schedule ” procedure . ( �P . 124 )
When a setting is changed , its icon
2
Electric Vehicle system
