114 2-2 . Charging
cle Settings ”, and then press and hold .
3 Press or of the meter
control switches to select “ Charging Settings ”, and then
press .
The “ Charging Settings ” screen will be displayed .
4 Press or of the meter
control switches to select “ DC charging power ”, and then press
.
The “ DC charging power ” screen will be displayed .
5 Press or of the meter
control switches to select the charging power from “ MAX ”, “ 125kW ”, “ 100kW ”, “ 75kW ”,
“ 50kW ” and then press .
The maximum power when charging
is limited to the selected power or less .
If “ MAX ” is selected , the vehicle will be charged with the maximum power that can be charged .
● Setting operations on multimedia
1 Select . 2 Select “ Vehicle customize ”. 3 Select “ Charging ”. 4 Select “ DC charging power ”.
5 Select from “ MAX ”, “ 75kW ”, “ 50kW ”.
The maximum power when charging is limited to the selected power or
less .
If “ MAX ” is selected , the vehicle will be charged with the maximum power that can be charged .
■ Changing the “ Charging Limit ” settings
�P . 107
■ If “ Check Charging System Close Charging Port Lid See Owner ’ s Manual ” is displayed on the multi-information display
If the system check after DC charging is not completed successfully , the EV system will not start even if the power switch is pressed
while depressing the brake pedal .
Perform a system check with the following procedures .
1 Be sure to engage the parking brake and then turn the power switch off .
2 Close the charging inlet cap , close the charging port lid .
3 Check if “ Checking Charging System ” is displayed on the multi-information display when
the power switch is turned to ON .
Do not open the charging port lid
while the charging system is checking .
When the system check is completed , the power switch automatically turns off .
4 Press the power switch while
depressing the brake pedal . The “ READY ” indicator turns on .
Contact your SUBARU dealer if the charging system check is done and the message on the multi-information display does not go off .
WARNING
■ Warnings for DC charging Be sure to observe the following when using DC charging .
Failure to do so may cause an accident that could lead to death or serious injury .
●Check that the DC charger and DC charging inlet are not damaged . If there is any damage to the DC charging inlet , do not
perform a DC charge and have it inspected immediately at your SUBARU dealer .
