5-4 . Using the driving support systems
333 rails , road repairs , white lines , pedestrian crossings or fallen leaves on the road
• Metal covers ( gratings ), such as those used for drainage ditches
• Objects reflected in a puddle or on a wet road surface
• Shadows on the road
●In some situations , such as the following , the rear camera detection function may operate even
though there are no pedestrians in the detection area .
• When backing up toward the roadside or a bump on the road
• When backing up toward an incline / decline
• If the rear of the vehicle is raised or lowered due to the carried load
• If a bumper protector , such as an
additional trim strip , is installed to the rear bumper
• If the orientation of the rear camera has been changed
• If a towing eyelet is installed to the rear of the vehicle
• When water is flowing over the rear camera lens
• When the rear camera is
obscured ( dirt , snow , ice , etc ., are attached ) or scratched
• If there is a flashing light in the
detection area , such as the emergency flashers of another vehicle
• When a tire chains or an emergency tire puncture repair kit is used
●Situations in which the rear camera detection function may be difficult to notice
• The buzzer may be difficult to hear if the surrounding area is noisy , the volume of the audio system
volume is high , the air conditioning system is being used , etc .
• If the temperature in the cabin is extremely high or low , the audio system screen may not operate correctly .
PKSB ( Parking Support Brake )
The Parking Support Brake system consists of the following functions that operate when driving at a low speed or backing up , such as when parking . When the system determines that the probability of a collision with a detected object or pedestrian is high , a warning operates to urge the driver to take evasive action . If the system determines that the possibility of a collision with a detected object or pedestrian is extremely high , the brakes are automatically applied to help avoid the collision or help reduce the impact of the collision .
PKSB ( Parking Support Brake ) system
■ Static Objects Front and Rear of the Vehicle
�P . 338
■ Moving Vehicles Rear of the Vehicle
�P . 340
■ Pedestrians Rear of the Vehicle ( if equipped )
�P . 344
5
Driving
