STARTING AND OPERATING 369
Example 1
S _ 703287-MW
The detection range of the rear radar sensors
Area out of detection range of the rear radar sensors
Vehicle that may not be detected Parked vehicle
WARNING
An approaching vehicle may not be detected because the detection range is limited by the parked vehicle. Always be sure to check the surroundings with your eyes when reversing the vehicle.
Example 2
S _ 703288-MW
The detection range of the rear radar sensors
Vehicle that may be detected
NOTE
The system may detect that a vehicle is passing in front of your vehicle. Always be sure to check the surroundings with your eyes when reversing the vehicle.
OPERATING CONDITIONS s07bm10
The BSW / RCTW will operate when all of the following conditions are met.
. The ignition switch is in the“ ON” position.
. The BSW / RCTW warning indicator and BSW / RCTW OFF indicator are turned off.
. The vehicle is driven at speeds above 7 mph( 12 km / h)( except when reversing).
. The select lever is in the“ R” position( RCTW only).
The BSW / RCTW will not operate in the following situations.
. The BSW / RCTW OFF indicator appears.
. The vehicle speed is below 6 mph( 10 km / h) even when the BSW / RCTW OFF indicator does not appear( except when reversing).
NOTE
. In the following cases, the BSW / RCTW will stop operating and the BSW / RCTW warning indicator will appear.
– When a malfunction occurs in the system, including the BSW / RCTW approach indicator light
. If the BSW / RCTW warning indicator appears, exercise proper caution. For details, refer to“ BSW / RCTW Warning Indicator” FP373.
. In the following cases, the BSW / RCTW will temporarily stop operating( or may stop operating) and the BSW / RCTW OFF indicator will appear.
– When the radar sensor becomes significantly misaligned( If the orientation of the radar sensor is
– CONTINUED –
