360
STARTING AND OPERATING
. The camera surface may be damaged by a flying stone. e. g., when the front view screen is displayed
NOTE
If the camera lens is covered in dirt, the system will not be able to produce a sharp image. If there is foreign material on the camera, such as water drops, snow or mud, clean it with water and wipe away any moisture with a soft cloth. If the camera is heavily soiled, wash it using a neutral detergent.
FRONT CROSS TRAFFIC IN- FORMATION( If Equipped) s07bu06
While the Surround View Monitor is being displayed, the presence of vehicles approaching from the left and right is indicated by icons. If the select lever is set to the“ D” position or the“ M” position and the system detects an approaching vehicle while the vehicle is stopped, the icon will illuminate.
If the system detects an approaching vehicle( including motorcycle) while the vehicle is traveling at a speed of approximately 13 mph( 20 km / h) or less, the icon will flash and alert the driver using a warning message, an alarm sound, and the EyeSight Assist Monitor display.
For details about the EyeSight Assist Monitor, refer to the Owner’ s Manual supplement for the EyeSight system.
NOTE
When the AUTO mode icon is activated on the Surround View Monitor and the system detects a vehicle, only the approaching vehicle icon will blink.
S _ 703514-W
When there is a vehicle approaching from the left
When there is a vehicle approaching from the right
WARNING
. The driver is responsible for driving safely. Before you start driving, check the vehicle surroundings with the brake depressed.
. Depending on the vehicle condition or the surrounding environment, the radar sensors ability to detect objects may become unstable.
. The system is not activated when the speed of an approaching vehicle is less than 3 mph( 5 km / h) or more than 37 mph( 60 km / h).
