INSTRUMENTS AND CONTROLS 231
3
Indicator Light HomeLink ® buttons
S _ 307928-W
2. Position the hand-held remote( garage door opener remote) 1 to 3 inches( 2 to 8 cm) away from the HomeLink ® button that you would like to program.
S _ 307665-W
NOTE
Some devices may require you to replace this“ Programming a New HomeLink ® button” step 3 with procedures noted in the“ Gate Operator / Canadian Programming” section. Refer to“ Gate Operator / Canadian Programming” FP233.
4. Press the HomeLink ® button that you would like to program and observe the indicator light.
S _ 307929-W
Garage door opener remote
NOTE
Some hand-held remotes( garage door opener remotes) may actually train better at a distance of 6 to 12 inches( 15 to 30 cm). Keep this in mind if you have difficulty with the programming process.
3. While the HomeLink ® indicator light is flashing orange, press and hold the hand-held remote button. Continue pressing the hand-held remote button until the HomeLink ® indicator light changes from orange to green. You may now release the hand-held remote button.
Indicator Light
S _ 307930-W
. If the indicator light remains constant green, your device should operate when the HomeLink ® button is pressed. At this point, if your device operates, programming is complete.
. If the indicator light rapidly flashes green, firmly press, hold for two seconds and release the HomeLink ® button up to three times to complete the programming process. At this point if your device operates, programming is com-
– CONTINUED –
