& SUBARU Advanced Frontal Airbag System, SRS Seat Cushion Airbag, SRS Side Airbag and SRS Curtain Airbag s01ah02
This vehicle is equipped with a SUBARU advanced frontal airbag system that complies with the new advanced frontal airbag requirements in the amended Federal Motor Vehicle Safety Standard( FMVSS) No. 208.
The SUBARU advanced frontal airbag system automatically determines the deployment force of the driver’ s SRS frontal airbag at the time of deployment as well as whether or not to activate the front passenger’ s SRS frontal airbag and, if activated, the deployment force of the SRS frontal airbag at the time of deployment.
|
This vehicle has warning labels on the driver’ s and front passenger’ s sun visors beginning with the phrase“ EVEN WITH ADVANCED AIR BAGS” and a tag attached to the glove box lid beginning with the phrase“ Even with Advanced Air Bags”. Make sure that you carefully read the instructions on the warning labels and tag.
Always wear your seatbelt. The SUBARU advanced frontal airbag system is a supplemental restraint system and must be used in combination with a seatbelt. All occupants should wear a seatbelt or be seated in an appropriate child restraint system.
This vehicle is equipped with a SUBARU SRS curtain airbag system that complies with the Federal Motor Vehicle Safety
|
Standard( FMVSS) No. 226.
For the locations of the SRS airbags, refer to“ Components” FP89.
In a moderate to severe frontal collision, the following components deploy.
. SRS frontal airbag for driver. SRS frontal airbag for front passenger
. SRS seat cushion airbag for front passenger
. SRS curtain airbag * 1. SRS knee airbag for driver * 1: When an offset frontal collision that is severe enough to deploy the front airbag occurs.
These components supplement the seatbelts by reducing the impact to the occupant’ s head, chest and knees.
In a moderate to severe side impact collision, the SRS side airbag on the impacted side of the vehicle deploys between the occupant and the door panel and supplements the seatbelt by reducing the impact to the occupant’ s chest and waist.
In a moderate to severe side impact collision, the SRS curtain airbag on the impacted side of the vehicle deploys between the occupant and the side window and supplements the seatbelt by reducing the impact to the occupant’ s
– CONTINUED –
|
1
Seat, Seatbelt and SRS Airbags
|
