SRS Airbag ( Supplemental Restraint System Airbag )
tration ( NHTSA ) website . In Canada , check with Transport Canada .
1-10 . SRS Airbag ( Supplemental Restraint System Airbag ) s01ah
Supplemental Restraint System ( SRS ) name is used because the airbag system supplements the vehicle ’ s seatbelts .
This vehicle is equipped with a supplemental restraint system which consists of eight airbags .
The configurations are as follows .
. Driver ’ s and front passenger ’ s frontal airbags
. Driver ’ s and front passenger ’ s side airbags
. Front passenger ’ s seat cushion airbags
. Curtain airbags ( for driver , front passenger , and window-side rear passengers )
. Knee airbag for driver
These SRS airbags are designed only to be a supplement to the primary protection provided by the seatbelt .
The system also controls front seatbelt pretensioners . For operation instructions and precautions concerning the seatbelt pretensioner , refer to “ Seatbelt Pretensioners ” FP58 .
& General Precautions Regarding SRS Airbag System s01ah10
WARNING
. To obtain maximum protection in the event of an accident , the driver and all passengers must always wear seatbelts when in the vehicle . The SRS airbag is designed only to be a supplement to the primary protection provided by the seatbelt . It does not eliminate the need to fasten seatbelts . Used in combination with the seatbelts , the SRS airbag offers vehicle occupants the best possible protection in the event of a serious accident .
Not wearing a seatbelt increases the chance of severe injury or death in a crash even when the vehicle has the SRS airbag .
For instructions and precautions concerning the seatbelt system , refer to “ Seatbelts ” FP48 .
. The SRS side airbags and SRS curtain airbags are designed only to be a supplement to the primary protection provided by the seatbelt . They do not eliminate the need to fasten seatbelts . It is also
