Child Restraint Systems 71 |
|||||||||
9. Pull at the shoulder portion of the belt to confirm that it cannot be pulled out( ALR properly functioning). |
Legacy |
10. Latch the top tether hook onto the tether anchorage that is located behind the rear seat and tighten the top tether firmly. For additional instructions, refer to“ Top Tether Anchorages” FP79. |
11. To remove the child restraint system, press the release button on the seatbelt buckle and allow the belt to retract completely. The belt will return to the ELR mode. |
NOTE
When the child restraint system is no longer in use, remove it and restore the ELR function of the retractor. That function is restored by allowing the seatbelt to retract fully.
& Installing a Booster Seat or Booster Cushion s01ag05
WARNING
NEVER INSTALL A BOOSTER SEAT / CUSHION ON THE FRONT PASSEN- GER’ S SEAT IF THE FRONT PAS- SENGER’ S FRONTAL AIRBAG ON INDICATOR LIGHT ILLUMINATES. DOING SO RISKS SERIOUS INJURY OR DEATH TO THE CHILD BY PLA- CING THE CHILD’ S HEAD TOO CLOSE TO THE SRS AIRBAG.
|
1
Seat, Seatbelt and SRS Airbags
|
||||
Outback / Subaru Outback Wilderness |
Remember that the head restraint is not intended to be used at the lowest position( retracted position). Therefore, when the rear center seat is occupied( including when a child restraint system is installed) next time, be sure to raise the head restraint to the extended position. |
||||||||
– CONTINUED – |
