When any of the tires are punctured, you can seal the tire temporarily. However, do not tow a trailer when a sealed tire is used. We recommend that you consult the nearest SUBARU dealer for details.
The maximum gross trailer weight and maximum gross tongue weight are indicated in the following table.
|
& Connecting a SUBARU Genuine Trailer Hitch s08ak01
1. Remove the receiver cover from the hitch receiver tube. Then insert the ball mount into the hitch receiver tube.
|
|||
|
Maximum gross trailer weight
3,500 lbs( 1,588 kg)
2,700 lbs( 1,224 kg)
|
Maximum gross tongue weight
350 lbs( 159 kg)
270 lbs( 122 kg)
|
|||
|
2.4 L turbo models
2.5 L non-turbo models
When towing a trailer, refer to“ Trailer Towing( Outback / Subaru Outback Wilderness)” FP473.
|
2. Insert the hitch pin into the hole located on the hitch receiver tube so that the pin passes through the ball mount. |
3. Insert the safety pin through the provided hole on the hitch pin securely.
4. Check the ball mount assembly by pulling on it to make sure it does not come off the hitch receiver.
|
8
Driving Tips
|
|||
– CONTINUED – |
||||||
