nate. |
The RAB OFF indicator will turn off when the corresponding function is turned ON.
NOTE
. When the settings cannot be changed, the ON / OFF setting key will be grayed out.
. The ON / OFF setting key may be grayed out if the Reverse Automatic Braking( RAB) system malfunctions, etc. In this case, turn the ignition switch to the“ OFF” position and then turn it to the“ ON” position again. If the setting cannot be changed even after turning the ignition switch to the“ ON” position again, we recommend that you consult your SUBARU dealer.
|
. As soon as you turn off the ignition switch, the Reverse Automatic Braking( RAB) ON / OFF setting is stored in the system. Therefore, when you turn the ignition switch from the“ OFF” state to the“ ON” position, the Reverse Automatic Braking( RAB) setting will revert to the state that was set before the ignition switch was turned off.
. As soon as you turn off the ignition switch, the Sonar Audible Alarm ON / OFF settings is stored in the system. Therefore, when you turn the ignition switch from the“ OFF” state to the“ ON” position, the Sonar Audible Alarm ON / OFF settings will revert to the state that was set before the ignition switch was turned off.
Also, the following settings can be changed by operating the center information display.
. Warning Volume. Sonar Audible Alarm
For details, refer to“ Car settings” FP232.
|
& RAB Warning Indicator
1 RAB malfunction message 2 RAB warning indicator
s07bn07
|
If the Reverse Automatic Braking( RAB) system malfunctions, the above indicator illuminates on the combination meter. Contact the nearest SUBARU dealer for details.
& Handling of the Sonar Sensors s07bn06
The 4 sonar sensors are located in the rear bumper. To ensure the proper operation of the Reverse Automatic Braking( RAB) system, observe the following precautions.
|
7
Starting and Operating
|
||
– CONTINUED – |
