BSD / RCTA 417 |
|||||
|
. On a road with extremely narrow lanes, the system may detect vehicles driving in a lane next to the neighboring lane.
& BSD / RCTA Approach Indicator Light / Warning Buzzer s07bm03
While the BSD / RCTA is active, the following item( s) will operate to alert the driver:
. The BSD / RCTA approach indicator light( when there are vehicles in the neighboring lanes).
. The BSD / RCTA approach indicator light and warning buzzer( when a vehicle is approaching from the left or right side while your vehicle is reversing)
|
! BSD / RCTA approach indicator light s07bm0301 |
BSD / RCTA approach indicator light
It is mounted on each side of the outside mirrors.
The indicator light will illuminate when a vehicle approaching from behind is detected.
The indicator light will flash to warn the driver of dangers under the following conditions.
. While the indicator light is illuminating, if the turn signal lever is operated toward the side in which this light turned on
. When reversing the vehicle while the system detects a vehicle approaching from either side
|
! BSD / RCTA approach indicator light dimming function s07bm030101
When the headlights are turned on, the brightness of the BSD / RCTA approach indicator light will be reduced.
NOTE
. You may have difficulty seeing the BSD / RCTA approach indicator light under the following conditions. – When sunlight shines directly on it
– When the headlight beams from a vehicle traveling behind shines directly on it
. While the illumination brightness control dial is in the fully upward position, even if the headlights are turned on, the brightness of the BSD / RCTA approach indicator light will not be reduced. For details about the illumination brightness control dial, refer to“ Illumination Brightness Control” FP181.
! BSD / RCTA approach warning buzzer( only when reversing) s07bm0302
A warning buzzer sounds along with flashing of the BSD / RCTA approach indicator light to warn the driver of dangers.
|
7
Starting and Operating
|
|
The setting of the warning buzzer volume |
|||||
– CONTINUED – |
